Abec-5  Radial Bearing 25x32x4mm , double shielded

1 pcs.

ABEC-5 Radial ball bearing 10X15X4

Radial ball bearing 5x13x5, Double shielded.

Miniature Ball Bearing 1.5X4X2

Ball Bearing 3x8x4

Ball Bearing 5x11x4

Hybrid Ceramic Ball bearings set for Multicopter Motor Avizar MC3536. Those are replacement Ball bearings set

Inclusive of 3 high performance Bearings

Details:

• 4x13x5mm (1pc)
• 4x8x3mm (2pcs)

To be used with Helicopter and Airplane engines :Webra 40-50-52,55,61

ceramic is the new Holy Grail! Its lighter, smoother, stiffer, harder, corrosion resistant, and electrically resistant. These fundamental characteristics allow for a wide range of performance enhancements in bearings. Ceramic bearings dissipate heat quickly, reducing friction and wear while maintaining a precision smooth surface. Today's leading edge ceramics are made with Silicon Nitride (Si3N4) and have characteristics similar to the heat absorbing, highly resilient tiles on the Space Shuttle as they protect it from the 2500 plus degrees F. extremes of re-entry into the earth's atmosphere. The use of Ceramics for bearing components results in a far superior product over traditional all steel ball bearings.

Set include 2 ceramic bearings, Front and Rear

The ceramic ball on the right is not only much lighter and impervious to corrosion, but also much more resistant to impact. Ceramic bearings earn their reduced friction due to much tighter roundness tolerances as compared to even the best steel bearings.

Those bearings are ABEC-7 standards, and perfect for All motors/engine applications, we use them as Upgrade-tuning to make the engine long life lasting.
The Bearing is made from Chrome steel, which is perfect for Moisture applications/environment.

Ceramic is the new Holy Grail! Its lighter, smoother, stiffer, harder, corrosion resistant, and electrically resistant. These fundamental characteristics allow for a wide range of performance enhancements in bearings. Ceramic bearings dissipate heat quickly, reducing friction and wear while maintaining a precision smooth surface. Today's leading edge ceramics are made with Silicon Nitride (Si3N4) and have characteristics similar to the heat absorbing, highly resilient tiles on the Space Shuttle as they protect it from the 1000C, extremes of re-entry into the earth's atmosphere. The use of Ceramics for bearing components results in a far superior product over traditional all steel ball bearings.

Silicon nitride is a chemical compound of the elements silicon and nitrogen. Si. ₃N. ₄ (Trisilicon tetranitride) is the most thermodynamically stable and commercially important of the silicon nitrides, and the term ″Silicon nitride″ commonly refers to this specific composition

The ceramic ball on is not only much lighter and impervious to corrosion, but also much more resistant to impact. Ceramic bearings earn their reduced friction due to much tighter roundness tolerances as compared to even the best steel bearings.

Specifications:

6202 Hybrid Ball bearing
Dimensions : 15X35X11mm
Bearing Material : Chrome steel 52100
Ball material : Silicon Nitride (Si3N4)
Cage: PTFE
Sealing: both side sealed
Abec Rating : Abec -7
Lube: SRL grease ( Non major brand)

Delivery scope: 1 ball bearing

Those bearings are ABEC-7 standards, and perfect for All motors/engine applications, we use them as Upgrade-tuning to make the engine long life lasting.
The Bearing is made from Chrome steel, which is perfect for Moisture applications/environment.

Ceramic is the new Holy Grail! Its lighter, smoother, stiffer, harder, corrosion resistant, and electrically resistant. These fundamental characteristics allow for a wide range of performance enhancements in bearings. Ceramic bearings dissipate heat quickly, reducing friction and wear while maintaining a precision smooth surface. Today's leading edge ceramics are made with Silicon Nitride (Si3N4) and have characteristics similar to the heat absorbing, highly resilient tiles on the Space Shuttle as they protect it from the 1000C, extremes of re-entry into the earth's atmosphere. The use of Ceramics for bearing components results in a far superior product over traditional all steel ball bearings.

Silicon nitride is a chemical compound of the elements silicon and nitrogen. Si. ₃N. ₄ (Trisilicon tetranitride) is the most thermodynamically stable and commercially important of the silicon nitrides, and the term ″Silicon nitride″ commonly refers to this specific composition

The ceramic ball on is not only much lighter and impervious to corrosion, but also much more resistant to impact. Ceramic bearings earn their reduced friction due to much tighter roundness tolerances as compared to even the best steel bearings.

Specifications:

6303 Hybrid Ball bearing
Dimensions : 17x47x14mm
Bearing Material : Chrome steel 52100
Ball material : Silicon Nitride (Si3N4)
Cage: PTFE
Sealing: both side sealed
Abec Rating : Abec -7
Lube: SRL grease ( Non major brand)

Delivery scope: 1 ball bearing

F605ZZ 5X14X5 Flanged Bearing
Single row, deep-groove ball bearing for applications that support high speeds, axial loads in both directions, and radial loads
Stainless steel cage evenly spaces balls for reduced friction, vibration, and noise CN (normal) radial clearance for applications where thermal expansion is not a factor

Measurements

•     Inner Diameter: 5
•     Outer Diameter: 14
•     Thickness: 5
•     Measurement Unit: Metric

Materials

•     Bearing Type: Radial Bearing
•     Product Seal: Two Metal Shield (ZZ)
•     Ball Material: Chrome Steel
•     Retainer Material: Metal or High Speed Plastic

Technical Specifications

•     Quantity: 1
•     Quality Level ABEC 5
•     Operating  Temperature:–30 °C to +110°C.
•     Raceways: Finely polished superior finish for long life, and low noise.
•     Lubrication  recommended: High Quality Synthetic bearing Lubricant.

Flanged Bearing 2x5x2.5F

Flanged Bearing 2x6x2.5F

Flanged Bearing 3x7x3F

Flanged Bearing 3x8x3.5F

Flanged Bearing 3x8x4F

Flanged Bearing 4x7x2.5F

Flanged Bearing 4x8X3F

Flanged Bearing 5x10x4F

Flanged Bearing 5x13x4F

Flanged Bearing 5x9x3F

1 pcs

Flanged Bearing 6x10X3

Flanged Bearing 6x12x4F

Flanged Bearing 6x13x5F .
Single row, deep-groove ball bearing for applications that support high speeds, axial loads in both directions, and radial loads
Metal shields on both sides of the bearing keep the lubricant in and contaminants out AISI 52100 chrome steel for durability and resistance to deformity under heavy loads
Stainless steel cage evenly spaces balls for reduced friction, vibration, and noise CN (normal) radial clearance for applications where thermal expansion is not a factor

Flanged Bearing  6X15X5F

Single row, deep-groove ball bearing for applications that support high speeds, axial loads in both directions, and radial loads
Metal shields on both sides of the bearing keep the lubricant in and contaminants out AISI 52100 chrome steel for durability and resistance to deformity under heavy loads
Stainless steel cage evenly spaces balls for reduced friction, vibration, and noise CN (normal) radial clearance for applications where thermal expansion is not a factor

Flanged Bearing  8x12x3.5F

Single row, deep-groove ball bearing for applications that support high speeds, axial loads in both directions, and radial loads
Metal shields on both sides of the bearing keep the lubricant in and contaminants out AISI 52100 chrome steel for durability and resistance to deformity under heavy loads
Stainless steel cage evenly spaces balls for reduced friction, vibration, and noise CN (normal) radial clearance for applications where thermal expansion is not a factor

Replace the stock bearings with these high precision bearings to ensure high precision and zero slop performance on your T-REX. 2 pcs in set

Specification:

Manufactured in Japan.

• Size: 5x11x5mm
• Quantity: 2
• Usage: for T-REX 450X Main Shaft Support

Miniature bearings are one of the most commonly used bearings. Often used in electric motors, radio controlled models, instrumentation and controls. These shielded type bearings provide some protection against contamination without generating any friction. Additional greasing is not required as they are pre-lubricated. Suitable for a wide variety of applications.

Inside Diameter: 3mm

Outside Diameter: 7mm

Width: 2.5mm

Seal Type: ZZ (Metal Shielded)

Scope of delivery- 1 Bearing

Miniature bearings are one of the most commonly used bearings. Often used in electric motors, radio controlled models, instrumentation and controls. These shielded type bearings provide some protection against contamination without generating any friction. Additional greasing is not required as they are pre-lubricated. Suitable for a wide variety of applications.

Inside Diameter: 3mm

Outside Diameter: 7mm

Width: 3mm

Seal Type: ZZ (Metal Shielded)

Scope of delivery- 1 Beating

MF63-ZZ Flanged Bearing ABEC-5 3x6x2.5mm
Single row, deep-groove ball bearing for applications that support high speeds, axial loads in both directions, and radial loads
Stainless steel cage evenly spaces balls for reduced friction, vibration, and noise CN (normal) radial clearance for applications where thermal expansion is not a factor

Measurements

•     Inner Diameter: 3
•     Outer Diameter: 6
•     Thickness: 2.5
•     Measurement Unit: Metric

Materials

•     Bearing Type: Radial Bearing
•     Product Seal: Two Metal Shield (ZZ)
•     Ball Material: Chrome Steel
•     Retainer Material: Metal or High Speed Plastic

Technical Specifications

•     Quantity: 1
•     Quality Level ABEC 5
•     Operating  Temperature:–30 °C to +110°C.
•     Raceways: Finely polished superior finish for long life, and low noise.
•     Lubrication  recommended: High Quality Synthetic bearing Lubricant.

Miniature Flanged Ball Bearing F 684 ZZ / 2Z 4x9x4 mm

Stainless steel bearings are more expensive but they will run at higher temperatures than chrome steel bearings and are also resistant to corrosion. Stainless steel bearings will cope with up to 300°C with the right lubricant while the load capacity of chrome steel bearings falls rapidly above 150°C.

This means that the life ratings for  steel bearings are higher , which makes them the best choice for most applications.

Radial ball bearing 12x24x6, DOUBLE shielded

Made in japan

Radial ball bearing 10x19x7
